Olíuskilja Oleopator-P-SD NS10-50/1000 m. framhjáhlaupi ACO

Olíuskilja með framhjáhlaupi Oleopator-P-SD NS10-50/1000 ACO

Eiginleikar

• Shaft buoyancy-proof up to the top of the manhole cover without on-site concrete works on extension systems with load class D 400
• Proven stability: min. 50 years according to German Standard DIN 19901
• According to EN 858
• Type test report
  • 7310434-01 (NS 3)
  • 7310434-02 (NS 6)
  • 7310434-03 (NS 8)
  • 7310434-03 (NS 10)
• Inlet and outlet connection according to outside diameter D depending on Nominal Size of separator
• Inlet and outlet parts of polyethylene
• With integrated removable coalescing filter
• Automatic closure device with float switch, density of float switch: 0.9 g/cm³
• With bypass of polyethylene
• Disposal and cleaning via cover
• With integrally formed raising tube for varying inlet heights
• Optionally upgradable with concrete supporting rings 60, 80 and 100 mm up to inlet invert Tmax
