Einstefnuloki Flangs m. Kúlu DN150 PN16

Einstefnuloki Hawle Flangs m. Kúlu DN150 PN16
Þyngd: 48 kg

Eiginleikar

Diameter range DN 50–DN 300

Pressure rating PN 10 I PN 16

• Prevents return flow through ball check principle
• Simple assembly and disassembly through single-sided loose flange with integrated flange gasket
• Drain opening in body
• Hinged lid with joint function for easy maintenance
• 100% corrosion protection
• Free passage
• Patent pending
• Face-to-face length according to EN 558-1 GR 48
• Flange sized in accordance with EN 1092-2, drilled according to EN 1092-2 PN 10 standard; EN 1092-2 | PN 16 DN 200 - 300 please specify on order -other standards on request
